Thông số kỹ thuật
| Graphics Processing | GeForce® GTX 1060 |
| Core Clock | Boost: 1771MHz/ Base: 1556 MHz in OC Mode |
| Memory Clock | 8008 MHz |
| Memory Size | 3 GB |
| Memory Type | GDDR5 |
| Memory Bus | 192 bit |
| Card Bus | PCI-E 3.0 x 16 |
| Output | Dual-link DVI-D *1 |
| Digital max resolution | 7680x4320 |
| Multi-view | 4 |
| Card size |
|
| PCB Form | Mini |
| DirectX | 12 |
| OpenGL | 4.5 |
| Recommended PSU | 300W |
Thông tin chi tiết
Custom-designed Cooling System
Equipped with 2 pure copper heat-pipes and 90 mm unique-blade fan with 3D active functionality, and heat pipes direct touch technology, the cooler can dissipate heat effectively from the GPU while keeping the fan at lower speed and noise.
Cooling System-Fan
Unique Blade Fan Design
The airflow is spilt by the triangle fan edge, and guided smoothly through the 3D stripe curve on the fan surface, effectively enhancing the air flow by 23% over traditional fans.
3D Active Fan
The semi-passive fans will remain off when the GPU is under a set loading or temperature for low power gaming. It allows gamers to enjoy gameplay in complete silence when the system is running light or idle.
Cooling System- Heat Pipes
Composite heat-pipes
The composite heat-pipes combines both thermal conductivity and phase transition for efficiently managing the transfer of heat between two solid interfaces which increases 29% of cooling capacity.
Heat Pipe Direct Touch
The pure copper heat pipes are shaped to maximize the direct contact area to the GPU.
Compact Card Size
Measuring merely 17cm in length, the card, perfectly compatible for building most of the PCs from ATX to mini-ITX.
Performance
One-click Super overclocking
With a simple click on XTREME engine utility, gamers can easily tune the card to meet their various gaming requirements without any overclocking knowledge, while saving the hassle of manual adjustment.
Durability
Ultra Durable Graphic Components
Engineered with the highest-grade chokes and capacitors, this graphic card delivers outstanding performance and durable system lifespan.
Intuitive Utility
Intuitive XTREME Engine Utility
Adjust clock speeds, voltage, fan performance, power target can be monitored and tuned in real-time according to your own preference through this intuitive interface. Download
(*The interface and functionality of the software is subject to each model.)
