Thông số kỹ thuật
| Thông tin chi tiết Card màn hình | |
| Hãng sản xuất | Gigabyte |
| Model | GeForce GTX 1080 G1 Gaming |
| GPU | GTX 1080 |
| RAM | 8GB GDDR5X 256bit |
| Engine Clock | Boost: 1860 MHz / Base: 1721 MHz in OC mode |
| Mem clock | 10010 MHz |
| Cuda core | 2560 Units |
| Cổng giao tiếp | DVI; HDMI; DisplayPort x 3 |
| DriectX/OpenGL | 12 / 4.5 |
| Chuẩn giao tiếp | PCI Express 3.0 x16 |
| Nguồn phụ | 8-pin |
| Công suất nguồn yêu cầu | 500W |
| Điểm nhấn | |
Thông tin chi tiết
| Chipset | GeForce® GTX 1080 |
| Core Clock | Boost: 1936 MHz / Base: 1784 MHz in OC mode Boost: 1898 MHz / Base: 1759 MHz in Gaming mode |
| Memory Clock | OC mode: 10400 MHz Gaming mode: 10206 MHz |
| Process Technology | 16 nm |
| Memory Size | 8 GB |
| Memory Bus | 256 bit |
| Card Bus | PCI-E 3.0 x 16 |
| Memory Type | GDDR5X |
| DirectX | 12 |
| OpenGL | 4.5 |
| PCB Form | ATX |
| Digital max resolution | 7680x4320@60Hz |
| Multi-view | 4 |
| I/O | Standard mode (Dual-link DVI-D*1, DP1.4*3, HDMI 2.0b*1) VR mode (Dual-link DVI-D*1, DP*1, HDMI*3) |
| Card size | H=56 L=289 W=138 mm |
| Power requirement | 500W ( WITH TWO 8-Pin EXTERNAL POWER CONNECTOR) |
| Accessories | Xtreme VR Link extended 5.25”front panel (2 HDMI ports and 2 USB3.0 ports) Xtreme VR Link extended bracket Xtreme SLI bridge XMP300 mouse pad Xtreme Gaming member club registration guide Graphics card quick manual Paper folder Wrist protector PCI-E Power cable x1 (Two 6pin to 8 pin) Xtreme Gaming Sticker |
