Thông số kỹ thuật
Thông tin chi tiết Card màn hình | |
Hãng sản xuất | Gigabyte |
Model | GeForce GTX 1080 G1 Gaming |
GPU | GTX 1080 |
RAM | 8GB GDDR5X 256bit |
Engine Clock | Boost: 1860 MHz / Base: 1721 MHz in OC mode |
Mem clock | 10010 MHz |
Cuda core | 2560 Units |
Cổng giao tiếp | DVI; HDMI; DisplayPort x 3 |
DriectX/OpenGL | 12 / 4.5 |
Chuẩn giao tiếp | PCI Express 3.0 x16 |
Nguồn phụ | 8-pin |
Công suất nguồn yêu cầu | 500W |
Điểm nhấn |
Thông tin chi tiết
Chipset | GeForce® GTX 1080 |
Core Clock | Boost: 1936 MHz / Base: 1784 MHz in OC mode Boost: 1898 MHz / Base: 1759 MHz in Gaming mode |
Memory Clock | OC mode: 10400 MHz Gaming mode: 10206 MHz |
Process Technology | 16 nm |
Memory Size | 8 GB |
Memory Bus | 256 bit |
Card Bus | PCI-E 3.0 x 16 |
Memory Type | GDDR5X |
DirectX | 12 |
OpenGL | 4.5 |
PCB Form | ATX |
Digital max resolution | 7680x4320@60Hz |
Multi-view | 4 |
I/O | Standard mode (Dual-link DVI-D*1, DP1.4*3, HDMI 2.0b*1) VR mode (Dual-link DVI-D*1, DP*1, HDMI*3) |
Card size | H=56 L=289 W=138 mm |
Power requirement | 500W ( WITH TWO 8-Pin EXTERNAL POWER CONNECTOR) |
Accessories | Xtreme VR Link extended 5.25”front panel (2 HDMI ports and 2 USB3.0 ports) Xtreme VR Link extended bracket Xtreme SLI bridge XMP300 mouse pad Xtreme Gaming member club registration guide Graphics card quick manual Paper folder Wrist protector PCI-E Power cable x1 (Two 6pin to 8 pin) Xtreme Gaming Sticker |
