Thông tin chi tiết
| Video Input | |||
|---|---|---|---|
| Video input format | HD-TVI 1080p/720p | ||
| Analog 960H/SD | |||
| Resolution / framerate | HD-TVI | 1920x1080 / 25, 30 FPS | |
| Analog 960H | 960x480 / 60i or 960x576 / 50i | ||
| Analog SD | 720x480 / 60i or 720x576 / 50i | ||
| Connectors | 4ch, 75Ω BNC connector | ||
| Video Output | |||
| Video output | HDMI VGA |
1, 4 split-screen |
|
|
HDMI: 1920 x 1080 |
|||
| VGA : 1920x1080, 1280x1024, 1024x768, 800x600 | |||
| User defined sequence / Alarm pop-up | |||
| Recording | |||
| Compression | H.264 / JPEG | ||
| Resolution | 1920 x 1080, 1280 x 720, 960 x 480(576) | ||
| Rate | Max. 30fps(25fps)@720p per channel, Max. 15fps(12fps)@1080p per channel | ||
| Quality | 10 levels up to 8Mbps | ||
| Mode | Manual & Event / Schedule & Event / Continuous & Event | ||
| Schedule | 24hrs / 7days | ||
| Playback | |||
| Mode | Instant playback / search | ||
| Speed | Max. 30fps(25fps)@720p per channel, Max. 15fps(12fps)@1080p per channel | ||
| Search type | Date/Time, Calendar/Time-line, Event, Thumbnail, Bookmark | ||
| Block playback | 24hours ~ 99days | ||
| Event & alarm | |||
| Event source | MD(Motion Detection), sensor, text, Video Loss | ||
| Event check schedule | 24hrs / 7days | ||
| Event action | Buzzer, Relay, E-mail, FTP, Alarm pop-up | ||
| MD area | 15x10 | ||
| Sensor input | Dry contact (NO or NC selectable) | ||
| Text input | POS/ATM support, AVE VSI Pro/Hydra support | ||
| System alarm | |||
| Alarm source | HDD fail, HDD almost full, Fan fail, Password fail, WRS fail | ||
| Alarm action | Warning message, Buzzer, E-mail, Relay | ||
| Audio | |||
| Input/output | 1ch RCA input / HDMI, 1 RCA output | ||
| Compression | ADPCM (32Kbps, 16KHz, 16bit sampleing) | ||
| Direction | Both | ||
| PTZ | |||
| Protocols | 41 models including C1080, C1080PT-Z20, Pelco-D, Pelco-P, Samsung, Panasonic and others |
||
| Network | |||
| Interface | 1 Ethernet (10/100Mbps) | ||
| Type | Static IP, Dynamic IP, xDSL | ||
| DDNS | WNS, DynDNS, NoIP, WRS | ||
| Bandwidth limit | Supported | ||
| NTP | Server / Client / Both | ||
| Users | 10 monitoring, 2 playback | ||
| Streaming | H.264 stream, High resolution 1 additional H.264 stream, Normal resolution 1 JPEG stream, Normal resolution for e-mail or mobile |
||
| Security | |||
| User level | 1 admin, 10 users | ||
| User privilege | Menu, PTZ, Relay, Playback, Power, Copy, Network MIC | ||
| IP filtering | Supported | ||
| Storage & Backup | |||
| Storage devices | 1 internal SATA HDDs | ||
| File system | Proprietary file system, data-loss protection against power-failure | ||
| Backup type |
Multi-channel or Single channel avi file |
||
| Backup device | USB drive (2 ports) | ||
| S.M.A.R.T. | Temperature and Health checking | ||
| Serial & I/O | |||
| Serial port | 1 RS-485 | ||
| Controller | |||
| Device | IR remote controller, Joystick Keyboard, Mouse | ||
| Software | |||
| Web viewer | Monitoring / Event / PTZ / Playback with IE | ||
| Java viewer | Monitoring / Event/ PTZ with IE, Chrome, Safari | ||
| Mobile viewer | Monitoring / PTZ / LogView / Playback / Audio / Push alarm with iPhone & Android | ||
| CMS | Control Center, Max. 1024 DVRs | ||
| SDK | ActiveX(COM) SDK | ||
| Environmental & physical | |||
| Dimension | 300(W) x 270(D) x 58(H) mm | ||
| Weight | 1.3 Kg (No HDD) | ||
| Operating temperature | 5°C~45°C (41°F ~ 113°F) | ||
| Power | DC 12V / 3A | ||
| Power consumption | Max. 9W (without HDD) | ||
| Approval | KC, FCC, CE | ||
